This machine is an automatic direct pressure vacuum filling machine. Mainly used in disinfectant liquid, pesticide, chemical, water, liquid bottles, sub packaging, can be applied to a variety of different shapes of containers. The utility model can be matched with a capping machine and a labeling machine to form a flow production line. It integrates light, electricity, electricity and gas. Control filling time to achieve different metering filling, filling time can be accurately controlled to one percent seconds. The filling process is completed on the touch screen under the control of the PLC program. It is a kind of easy to operate filling machine. With stable and reliable operation, high production efficiency, strong adaptability, can change the measurement to the specifications of filling in several minutes. Imported brand filling valve, advanced technology and precision, no leakage when filling.
Powerrig Machine is one of the toppest disinfectant filling machine, hand sanitizer bottle filling machine, hand sanitizer packaging machine factory.During these years of exporting, Powerrig Machine now has rich experience in the worldwide markets.
-
Every filling head has anti-drop design. It promise do not waste the material. And diameter of filling head basis on the diameter of customer’s barrel’s mouth.
-
Liquid Valves and Material Pipes
The valves are connected with the material pipes, and hand wheel is to adjust the heights of filling heads.
-
The material tank is used for liquid storage. And this tank can be SUS 316 material since it contacts filling liquid.
-
The width of guardrail on both sides of the conveyor belt should be adjusted according to the bottle size to ensure that the bottle can pass smoothly.
|
Filling head |
12heads |
|
Speed |
≤2000BPH (base on 1000ml water) |
|
Filling volume |
500-1000ml |
|
Suitable bottle diameter |
Ф40-Ф100mm |
|
Voltage |
220V/380V |
|
Power |
1kw |
|
Measure error |
≤±1‰ |
|
Working Pressure |
0.55Mpa-0.65Mpa |
|
Dimension |
2000mm × 900mm× 2500mm |
|
Weight |
500 kg |
